NETGEAR S350v2 Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black (GS348TP200NAS)
Product overview
NETGEAR S350v2. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Features
- One-wire installation with 8, 24, or 48 Gigabit ports with PoE+ options (55W, 190W or 380W PoE total budget) and 2 or 4 SFP ports options provide not only redundant uplinks, but also build dual redundancy by a trunked uplink with link aggregation and failover redundancy
- Quiet and Cost-effective Smart L2/L2+ switches with essential business class network needs, ideal for voice video and data convergence in office application
- Smart switch features include VLAN, ACL, QoS, IGMP
- Snooping, LACP Link aggregation, STP and SNMP for enhanced security and reliability
- Easy-to-use Web browser-based management GUI and full control through NETGEAR Smart Control Center, no need for an IT expert
- 3-year hardware warranty with 90-day free technical support
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GS348TP-200NAS |
| D&H SKU | GS348TP200NAS |
| UPC / GTIN | 606449175967 |
| MAC address table | 16000 entries |
| Switching capacity | 104 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Packet buffer memory | 1.5 MB |
| Product color | Black |
| Form factor | 1U |
| Rack mounting | Yes |
| Number of fans | 2 fan(s) |
| Built-in processor | Yes |
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| ARP inspection | Yes |
| MIB support | Y |
| Internal memory | 512 MB |
| Multicast support | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
| Web-based management | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Private VLAN, Voice VLAN |
| Number of VLANs | 256 |
| Rate limiting | Yes |
| Spanning tree protocol | Yes |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Quick start guide | Yes |
| User guide | Yes |
| Manual | Yes |
| LED indicators | Yes |
| Auto-negotiation | Yes |
| Noise level | 36.3 dB |
| Memory type | RAM |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 4 |
| Power source | PoE |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 48 |
| Total Power over Ethernet (PoE) budget | 380 W |
| Processor frequency | 800 MHz |
| DHCP features | DHCP client |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Loop protection | Yes |
| Flash memory | 64 MB |
| Shipping (inner) case height | 17" (43.2 cm) |
| Shipping (inner) case width | 22.3" (56.7 cm) |
| Shipping (inner) case length | 9.49" (24.1 cm) |
| Shipping (inner) case net weight | 29.3 lbs (13.3 kg) |
| Quantity per shipping (inner) case | 2 pc(s) |
| Width | 17.3" (440 mm) |
| Depth | 12.4" (316 mm) |
| Height | 1.69" (43 mm) |
| Weight | 8.93 lbs (4.05 kg) |
| Warranty period | 3 year(s) |
