NETGEAR GS305P Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Desktop/Wall-Mounting Black (GS305P300NAS)
Product overview
PLUG-AND-PLAY \nSimple set up with no software to install or configuration needed and zero maintenance\n\n FULL PERFORMANCE \nNon-blocking switching architecture for maximum throughput at wire speed\n\n POWER-OVER-ETHERNET \n4 PoE ports with 55W total power budget to power wireless AP, IP Cameras, IP Phones and much more\n\n PoE POWER AUTO-BALANCE AND ALLOCATION \nNETGEAR's unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs.\n\n SILENT OPERATION \nThe fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments\n\n ENERGY EFFICIENT \nDesigned to optimize power usage lowering its cost to operate.\n\n Metal Case \nDurable and Rugged\n\n VERSATILE MOUNTING OPTIONS \nSupports desktop and wall placement. Includes wall mount kit in the box\n\n STANDARDS-BASED DESIGN \nEnsure interoperability with any standards-based PDs
Features
- 5 Gigabit Ethernet ports
- Plug-and-play setup without configuration
- 4 PoE+ ports with a 63W total power budget
- Desktop installation
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GS305P-300NAS |
| D&H SKU | GS305P300NAS |
| UPC / GTIN | 606449163155 |
| MAC address table | 2000 entries |
| Switching capacity | 10 Gbit/s |
| Forwarding rate | 1.448 Mpps |
| Latency (1 Gbps) | 2.4 µs |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
| Packet buffer memory | 0.128 MB |
| Packet forwarding rate (1 Gbps) | 1448000 pps |
| Product color | Black |
| Wall mountable | Yes |
| Form factor | Desktop/Wall-Mounting |
| Housing material | Metal |
| Rack mounting | No |
| Stackable | No |
| Mean time between failures (MTBF) | 4113947 h |
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.3az, IEEE 802.3at, IEEE 802.3af, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Full duplex | Yes |
| Cable length detection | Yes |
| Half duplex | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Heat dissipation | 228.38 BTU/h |
| LED indicators | Yes |
| Auto MDI/MDI-X | Yes |
| Fanless | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power consumption (max) | 66.78 W |
| Input current | 1.25 A |
| Power connector | DC-in jack |
| Power source | DC/PoE |
| DC input voltage | 54 V |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 63 W |
| Power over Ethernet (PoE) ports quantity | 4 |
| MAC address filtering | Yes |
| Width | 6.22" (158 mm) |
| Depth | 3.98" (101 mm) |
| Height | 1.06" (27 mm) |
| Weight | 14.1 oz (400 g) |
