NETGEAR GS728TPP Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Gray (GS728TPP300NAS)
Product overview
Total Network Solution helps you get the most out of your network \nEasily deploy, manage, and monitor NETGEAR Insight managed routers, switches, and access points all from a single pane-of-glass.
Features
- Auto Negotiation of speed and duplex modes
- IEEE 802.3x Flow Control
- Dynamic MAC address management
- IEEE 802.1Q-based VLAN
- Auto Voice VLAN
- Auto Video VLAN (selected models)
- VLAN routing (selected models)
- QoS based on WRR, strict priority, or both
- Port-based and IEEE 801.2p-based QoS
- TCP/UDP-based QoS
- DiffServ
- IPv4 and IPv6-based QoS (selected models)
- DSCP Support
- Rate Limiting (ingress, or egress)
- Link Aggregation and LACP
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GS728TPP-300NAS |
| D&H SKU | GS728TPP300NAS |
| UPC / GTIN | 606449162370 |
| MAC address table | 16000 entries |
| Switching capacity | 56 Gbit/s |
| Forwarding rate | 41.67 Mpps |
| Latency (1 Gbps) | 4.701 µs |
| Packet buffer memory | 1.5 MB |
| Latency (10-100 Mbps) | 8.871 µs |
| Product color | Gray |
| Form factor | 1U |
| Housing material | Metal |
| Rack mounting | Yes |
| Number of fans | 2 fan(s) |
| Mean time between failures (MTBF) | 1252990 h |
| Built-in processor | Yes |
| Switch type | Managed |
| Switch layer | L2/L3/L4 |
| ARP inspection | Yes |
| Cloud-managed | Yes |
| Internal memory | 512 MB |
| Multicast support | Yes |
| Number of multicast groups filtered | 512 |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.3x |
| 10G support | No |
| VLAN support | Yes |
| IPv4 routes | 32 |
| IPv6 routes | 32 |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Certification | CE, FCC Class A, RCM, ICES Class A, VCCI, KC, BSMI, UKCA |
| Noise level | 33.3 dB |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 4 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| USB Type-A ports quantity | 1 |
| Power consumption (max) | 427 W |
| Power source | DC/PoE |
| Power supply included | Yes |
| Number of power supply units | 1 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 380 W |
| Processor manufacturer | ARM |
| Processor model | ARM Cortex-A55 |
| Processor frequency | 800 MHz |
| DHCP features | DHCP snooping, DHCP client |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) IPv4 entries | 100 |
| Flash memory | 64 MB |
| Width | 17.3" (440 mm) |
| Depth | 10.1" (257 mm) |
| Height | 1.7" (43.2 mm) |
| Weight | 9.06 lbs (4.11 kg) |
