NETGEAR GS108E-400NAS network switch Unmanaged L2/L3 Gigabit Ethernet (10/100/1000) Gray (GS108E400NAS)
Product overview
8-Port Gigabit Ethernet Easy Smart Managed Switch\n\nOn top of the plug-n-play Gigabit Ethernet connectivity, the NETGEAR GS108E switch offers essential networking features such as VLAN, QoS, IGMP Snooping, rate limiting, traffic monitoring and more. NETGEAR Easy Smart Managed Switches are an exceptional value for businesses looking to add intelligence to their network beyond what unmanaged switches can provide.
Features
- Gigabit Ethernet
- 8 ports provide gigabit Ethernet connectivity to your devices
- Energy-Efficient
- This switch is designed to optimize power usage, lowering cost of operation as a result
- No Crossover Cables
- Auto-MDI/MDIX eliminates the need for crossover cables
- Auto-Negotiation
- Automatic connection at the highest common speed between the switch and an end device
- Fanless Design
- Silent operation makes this switch perfect for noise-sensitive environments
- Versatile Mounting Options
- Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GS108E-400NAS |
| D&H SKU | GS108E400NAS |
| UPC / GTIN | 606449169942 |
| MAC address table | 4000 entries |
| Switching capacity | 16 Gbit/s |
| Product color | Gray |
| Mean time between failures (MTBF) | 2463431 h |
| Switch type | Unmanaged |
| Switch layer | L2/L3 |
| Multicast support | Yes |
| Number of multicast groups filtered | 128 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Port mirroring | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Tagged VLAN |
| Number of VLANs | 64 |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Heat dissipation | 8.9 BTU/h |
| LED indicators | Activity, Link, Power, Speed, System |
| Cable types supported | Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e, Cat8, Cat8.1 |
| Fanless | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power consumption (max) | 3.7 W |
| Input current | 1.5 A |
| Power source | DC |
| DC input voltage | 12 V |
| Power supply included | Yes |
| Access Control List (ACL) | Yes |
| Width | 6.22" (158 mm) |
| Depth | 3.98" (101 mm) |
| Height | 1.14" (29 mm) |
| Weight | 17.9 oz (508 g) |
