NETGEAR MS305-100NAS network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black (MS305100NAS)
Product overview
The NETGEAR 5-port Multi-Gigabit Unmanaged Switch, MS305, helps businesses cost-effectively expand their networks with multi-gig speeds. The MS305 Multi-Gigabit Ethernet switch comes with five (5) 2.5G ports in a metal case and can be placed on a desk or mounted on a wall with the included wall mount kit. This switch is energy efficient, built to last, and rigorously tested to provide the reliability businesses need. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.\n\n RELIABLE PERFORMANCE \nSuperior network performance at non-blocking rate delivers true Multi-Gig speed with no compromise\n\n ENERGY EFFICIENT \nEnergy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected\n\n PLUG-AND-PLAY \nNo software to install. No configuration needed. Zero maintenance required\n\n SILENT OPERATION \nThe fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments\n\n VERSATILE MOUNTING OPTIONS \nInstall your switch on your desktop, or mount it to your wall with the hardware provided in the box.
Features
- 5 Ethernet ports supporting 100Mbps, 1Gbps and 2.5Gbps
- Plug-and-play setup without configuration
- Metal enclosure
- Desktop or wall installation
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | MS305-100NAS |
| D&H SKU | MS305100NAS |
| UPC / GTIN | 606449160130 |
| Compliance certificates | CCC, Low Voltage Directive (LVD) |
| Latency (1 Gbps) | 2458 µs |
| Jumbo frames support | Yes |
| Jumbo frames | 9720 |
| Packet buffer memory | 1 MB |
| Product color | Black |
| Wall mountable | Yes |
| Housing material | Metal |
| Rack mounting | No |
| Stackable | No |
| Number of fans | 0 fan(s) |
| Input voltage | 12 V |
| Mean time between failures (MTBF) | 1401743 h |
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3x |
| Full duplex | Yes |
| Cable length detection | Yes |
| Half duplex | Yes |
| Head-of-line (HOL) blocking | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| LED indicators | Yes |
| Auto MDI/MDI-X | Yes |
| Noise level | 0 dB |
| Fanless | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Power consumption (typical) | 4.6 W |
| Power consumption (max) | 9.24 W |
| Input current | 1 A |
| Power source | DC |
| DC input voltage | 12 V |
| Power supply included | Yes |
| Power over Ethernet (PoE) | No |
| Width | 6.22" (158 mm) |
| Depth | 3.98" (101 mm) |
| Height | 1.14" (29 mm) |
| Weight | 16.9 oz (480 g) |
