NETGEAR GS748PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Gray (GS748PP100NAS)
Product overview
POWER-OVER-ETHERNET \n\n24 PoE+ ports delivering up to 30W per port with a 380W total power budget for wireless APs, IP Cameras, IP Phones and much more. Dynamic PoE maximizes usage of PoE budget.\n\n PLUG-AND-PLAY \n\nSimple set up with no software to install or configuration needed\n\n NON-BLOCKING SWITCHING \n\nNon-blocking switching architecture for maximum throughput at wire speed\n\n DYNAMIC FANS \n\nOptimal balance between noise and performance.\n\n VERSATILE MOUNTING OPTIONS \n\nInstall your switch on your desktop or mount it to your rack with the hardware provided in the box\n\n ENERGY EFFICIENT \n\nEnergy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Features
- 48 Gigabit Ethernet ports
- Plug-and-play setup without configuration
- 24 PoE+ ports with a 380W power budget
- Rack or desktop installation
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GS748PP-100NAS |
| D&H SKU | GS748PP100NAS |
| UPC / GTIN | 606449174908 |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), KC, Low Voltage Directive (LVD), RCM, UL, VCCI |
| MAC address table | 8000 entries |
| Jumbo frames support | Yes |
| Jumbo frames | 12.288 |
| Packet buffer memory | 1.5 MB |
| Product color | Gray |
| Rack mounting | Yes |
| Number of fans | 2 fan(s) |
| Redundant fans support | Yes |
| Mean time between failures (MTBF) | 570972 h |
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.3az |
| Copper ethernet cabling technology | 10BASE-T |
| Full duplex | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Heat dissipation | 34.2 BTU/h |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power consumption (max) | 410 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 8 A |
| Power source | AC/DC |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 380 W |
| Width | 17.3" (440 mm) |
| Depth | 12.2" (310 mm) |
| Height | 1.69" (43 mm) |
| Weight | 10.1 lbs (4.6 kg) |
| Warranty period | 2 year(s) |
