NETGEAR GSM4328 Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black (GSM4328100NES)
Product overview
Groundbreaking AV GUI \nA simplified user interface makes it easy to assign configuration profiles to each port.\n\n Multicast in an Instant \nNETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.\n\n Sleek, Quiet Design \nLess fan noise, and mounting ears included for rack mounting.\n\n Automatic Configuration \nAuto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.\n\n FAST, EASY\nCONFIGURATION\nFOR AV PROS \n\nA streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.\n\n FOCUS ON THE EVENT\nNOT FAN NOISE \n\nMost models have quiet mode which greatly reduces fan noise.\n\n DESIGNED FOR\nAV OVER IP\nRIGHT OUT OF\nTHE BOX \n\nWith built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
Features
- 24 Gigabit PoE+ ports with 4 10GBASE-X SFP+ uplinks
- 880W internal power supply providing 648W of PoE budget
- 1 slot for modular power supply (1+1 redundancy and/or EPS share)
- Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used
- The PoE budget can reach 720W, when the redundant PoE budget remains 648W
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
- Layer 3 feature set includes static, policy-based, and dynamic routing
- NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
- NETGEAR ProSAFE® Limited Lifetime Hardware Warranty
- Lifetime Next Business Day Hardware Replacement
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GSM4328-100NES |
| D&H SKU | GSM4328100NES |
| UPC / GTIN | 606449161922 |
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| Packet buffer memory | 16 MB |
| Throughput | 95.23 Mpps |
| Product color | Black |
| Form factor | 1U |
| Rack mounting | Yes |
| Stackable | Yes |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Traffic shaping | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Web-based management | Yes |
| 10G support | Yes |
| VLAN support | Yes |
| Number of VLANs | 4093 |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Noise level | 52 dB |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP+ modules quantity | 4 |
| Power source | AC |
| Power supply included | Yes |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 648 W |
| DHCP features | DHCP server, DHCP snooping, DHCPv6 snooping |
| Width | 17.3" (440 mm) |
| Depth | 15.7" (400 mm) |
| Height | 1.7" (43.2 mm) |
| Weight | 14.1 lbs (6.41 kg) |
