NETGEAR GS116EP Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Gray (GS116EP100NAS)
Product overview
GIGABIT ETHERNET AND FIBER \n\n15 ports provide Gigabit Ethernet connectivity to your devices and 1 SFP fiber port for long distance connections\n\n EASY POE CONTROLS \n\nManage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices\n\n VERSATILE MOUNTING OPTIONS \n\nPlace your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments\n\n VLANS \n\nPort-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources\n\n FANLESS DESIGN \n\nSilent operation makes this switch perfect for noise-sensitive environments\n\n ENERGY EFFICIENT \n\nEnergy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Features
- 15 Gigabit Ethernet ports and 1 SFP port
- Web-based Easy Smart management
- 15 PoE+ ports with a 180W budget
- VLAN and QoS controls
- Fanless operation
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part number | GS116EP-100NAS |
| D&H SKU | GS116EP100NAS |
| UPC / GTIN | 606449174823 |
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), KC, VCCI |
| MAC address table | 8000 entries |
| Switching capacity | 1 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 10000 |
| Packet buffer memory | 4.1 MB |
| Product color | Gray |
| Housing material | Metal |
| Mean time between failures (MTBF) | 784742 h |
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Number of multicast groups filtered | 128 |
| Ethernet LAN data rates | 1000 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.3az |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN |
| Number of VLANs | 64 |
| Rate limiting | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Quick start guide | Yes |
| Manual | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 1 |
| SFP module slots quantity | 1 |
| Power consumption (max) | 198.7 W |
| Power source | AC/DC |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 15 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 180 W |
| IGMP snooping | Yes |
| Queue scheduling algorithms | Strict Priority Queue (SPQ), Weighted Round Robin (WRR) |
| Width | 11.3" (286 mm) |
| Depth | 3.98" (101 mm) |
| Height | 1.06" (27 mm) |
| Weight | 29.3 oz (830 g) |
| Warranty period | 5 year(s) |
