DELL Pro 55 Plus P5525QC Digital signage flat panel 54.64" LCD 400 cd/m² 4K Ultra HD Black
Product overview
Made for team collaboration, this monitor provides up to 90W power delivery via USB-C and flexibility to include an OptiPlex Micro based on your needs.
Specifications
| Brand | DELL |
|---|---|
| Manufacturer part number | DELL-P5525QC |
| D&H SKU | P5525QC |
| UPC / GTIN | 884116469438 |
| Number of built-in speakers | 2 |
| Total carbon footprint (kg of CO2e) | 927 |
| Carbon emissions, manufacturing (kg of CO2e) | 377.29 |
| Carbon emissions, logistics (kg of CO2e) | 63.04 |
| Carbon emissions, energy usage (kg of CO2e) | 373.58 |
| Carbon emissions, end-of-life (kg of CO2e) | 112.17 |
| PAIA version | GaBi version 1, 2024 |
| Compliance certificates | RoHS |
| Product color | Black |
| Placement supported | Indoor |
| Product design | Digital signage flat panel |
| Display diagonal | 54.64" |
| Display resolution | 3840 x 2160 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | IPS |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Display number of colors | 1.07 billion colors |
| LED backlight | Yes |
| Anti-glare screen | Yes |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.0124 x 0.0124" (0.315 x 0.315 mm) |
| Color gamut | 72% |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1152, 2560 x 1440, 3840 x 2160 |
| Horizontal scan range | 30 - 140 kHz |
| Vertical scan range | 24 - 75 Hz |
| Surface hardness | 3H |
| Color depth | 8 bit |
| Display brightness | 400 cd/m² |
| Display diagonal (metric) | 54.6" (138.8 cm) |
| LED backlighting type | Edge-LED |
| Active display area (W x H) | 47.6 x 26.8" (1209.6 x 680.4 mm) |
| Haze rate | 25% |
| VESA mounting | Yes |
| Panel mounting interface | 300 x 400 mm |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| Purpose | Commercial |
| Built-in speaker(s) | Yes |
| RMS rated power | 20 W |
| Ethernet LAN | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 5 - 90% |
| Ethernet LAN (RJ-45) ports | 1 |
| Remote control battery | AAA x 2 |
| Cables included | AC, DisplayPort, HDMI, USB, USB Type-C |
| Quick start guide | Yes |
| Handheld remote control | Yes |
| Package weight | 74.5 lbs (33.8 kg) |
| Supported video modes | 480p, 576p, 720p, 1080i, 1080p, 2160p |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| DVI port | No |
| USB Power Delivery up to | 90 W |
| DC-in jack | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB port | Yes |
| USB 2.0 Type-B ports quantity | 1 |
| RS-232C | Yes |
| Power consumption (typical) | 77.1 W |
| Power consumption (max) | 300 W |
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 77 kWh |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Sustainability certificates | ENERGY STAR, TCO |
| Doesn't contain | Arsenic, Mercury, PVC/BFR |
| Bezel width (side) | 0.744" (1.89 cm) |
| Bezel width (top) | 0.744" (1.89 cm) |
| Bezel width (bottom) | 1.12" (2.85 cm) |
| Width | 49.1" (1247.4 mm) |
| Depth | 3.14" (79.8 mm) |
| Height | 28.7" (727.8 mm) |
| Weight | 49.4 lbs (22.4 kg) |
